Actor Class Reference

Class for anything that animates and has a position. Animates and has position and collision. More...

#include <Actor.hpp>

Inheritance diagram for Actor:

Collaboration diagram for Actor:

Public Member Functions
	Actor (sf::Texture &texture, sf::Shape *collisionMask, sf::Vector2f const &maskOffset)
	Actor (tinyxml2::XMLElement *xml)
void	animate (sf::Time const &elapsedTime)
	Updates the animator and applies it to ourself.
bool	isPlayingAnimation () const
	Returns true if an animation is currently playing.
std::string	getPlayingAnimation () const
	Gets the name of the playing animation. Undefined behaviour if no animation playing.
void	playAnimation (std::string const &name, bool loop=false)
	Begins playing an animation by name.
void	setVisible (bool isVisible=true)
bool	toggleVisible ()
bool	getVisible () const
virtual void	draw (sf::RenderTarget &target) const
Public Member Functions inherited from collision::Collidable
	Collidable (sf::Shape *mask, sf::Vector2f offset)
	Collidable (Collidable const &other)
	Collidable (tinyxml2::XMLElement *xml)
	Constructs a Collidable from an xml tag. Tag requires pointCoint and type attributes in addition to child tags depending on type specified. More...
const sf::Shape *	getMask () const
void	setMask (sf::Shape *mask, sf::Vector2f offset)
virtual void	onCollide (std::shared_ptr< Collidable > &other, sf::Vector2f const &mtv)
	Called when we collide with something.
void	setDebugColour (sf::Color const &c)
void	debug_draw (sf::RenderTarget &target)
void	getAxies (std::vector< sf::Vector2f > &axiesVector)
	Gets all axies of the mask. Gets all axies of the mask. Currently inefficient due to the fact that it iterates over all points and returns all axies (a duplicate of each axis is included!). More...
size_t	getPointCount () const
	Gets the number of points in the mask. Calls mask->getPoint() and returns the result.
sf::Vector2f	projectOntoAxis (sf::Vector2f &axis) const
	Projects the mask onto an axis. Projects each point of the mask onto an axis and returns the min and max points it covers on that axis. More...

Protected Attributes
bool	mVisible

Private Attributes
thor::Animator< sf::Sprite, std::string >	mAnimator
	Used to animate ourself.

Additional Inherited Members
Protected Member Functions inherited from collision::Collidable
void	updateCollidableMask (sf::Vector2f const &newPosition)
	Updates the position of the mask. Updates the position of the mask to equal newPosition plus the offset. More...

Detailed Description

Class for anything that animates and has a position. Animates and has position and collision.

Remarks

Used for things like Pawns, Minions, Towers, etc...

Constructor & Destructor Documentation

Actor::Actor	(	sf::Texture &	texture,
		sf::Shape *	collisionMask,
		sf::Vector2f const &	maskOffset
	)

Parameters

texture	Spritesheet to be used for animation
collisionMask	Shape of actor used in collision checks
maskOffset	Position of the collisionMask relative to Actor position

---

The documentation for this class was generated from the following file:

• include/Actor.hpp
